UPPER KALEKÖY HEPP (3x201,8MW , 1x20,64MW)

380 kV switchyard equipments and transmission line between PH and Switchyard installation, 3x201,8MW and 1x20,64MW power transformers installation, oil filling and treatment, Units IPB installation, MV connections, station service equipments, diesel generator, UPS, power and control cables installation, Unit control and 380 kV switchyard control systems, signalling systems, unit protection systems ve measuring equipments installation.Mechanical installation, test and commissioning support of one generator (30,64 MVA) ve one vertical Francis turbine and auxiliaries (cooling and lubrication equipment and piping lines)

ALPASLAN II HEPP (2x116,73 MW + 2x31,33 MW)

Mechanical erection, test and commissioning support of generators (2x116,73 MW + 2x31,33 MW), four vertical francis turbines, four inlet valves and related BOP & auxiliaries. Scope includes also design, equipment supply, erection and commissioning of complete Mechanical BOP. Electrical basic and detailed design, equipment supply, panel manufacturing, erection, test and commissioning of electrical LV and MV BOP & Protection & 380kV switchyard on turnkey basis. Other Works in the Scope of This Project Mechanical Design of LP Compressed Air System, Cooling Water System, Drainage&Dewatering Systems, Oil Treatment System.

ARKUN HEPP (3x76,6 MVA) MAIN PLANT

Mechanical erection,test and commissioning support of generators (3x76,6  MVA), three vertical francis turbines, three inlet valves and related BOP & auxiliaries. Scope includes also design, equipment supply, erection and commissioning of complete Mechanical BOP Electrical basic and detailed design, equipment supply, panel manufacturing, erection, test and commissioning of electrical LV and MV BOP & Protection & 380kV switchyard (Including switchyard civil work) on turnkey basis. Other Works in the Scope of This Project Basic and detailed design, equipment supply, panel manufacturing, erection, test and commissioning of 3 x 100 MVA  13,8/380 kV transformers and 2 Nos 380 kV Feeder. Basic and detailed design, equipment supply, erection, test and commissioning of  1500 m 1x630 mm2, 380/220 kV high voltage cable. Mechanical Design of LP Compressed Air System, Cooling Water System, Drainage&Dewatering Systems.

SHUAKHEVI HEPP (2x99,28MVA)

Electrical Basic and Detailed Design, Equipment Supply, Erection, Test and Commissioning of Electrical LV BOP & Protection & 220kV High Voltage Power Cables on Turnkey Basis. Mechanical Erection,Test and Commissioning Support of Generators (2x99,28 MVA), Two Vertical Francis Turbines & Two Inlet Valves and Related BOP & Auxiliaries, two 82/102,5 MVA Step-up Transformers, 220kV Gas Insulated Switchgear and MV BOP. Scope includes also Design, Equipment Supply, Erection and Commissioning of complete Mechanical BOP. Other Works in the Scope of This Project Mechanical Design of LP Compressed Air System, Cooling Water System, Drainage&Dewatering Systems, Oil Treatment System.

LOWER KALEKÖY HEPP (3 x 155,49 MW)

Design, equipment supply, erection  and commissioning of all auxiliary systems MBoP (Cooling Water System, Drainage, LP & HP Compressed Air System) of the plant. Erection of full EBoP & 380 kV Switchyar 3 x 155,49 MW Francis Type turbines and auxiliary systems.

PARAVANİ HEPP (2x52 MVA)

Mechanical Erection,Test and Commissioning Support of Generators (2x52  MVA), Two Vertical Francis Turbines & Two Inlet Valves and Related BOP & Auxiliaries. Scope Includes Also Design, Equipment Supply, Erection and Commissioning of Complete Mechanical BOP. Electrical Basic and Detailed Design, Equipment Supply, Panel Manufacturing, Erection, Test and Commissioning of Electrical LV and MV BOP & Protection & 220kV Switchyard (Including switchyard civil work) on Turnkey Basis. Other Works in the Scope of This Project Basic and Detailed Design, Equipment Supply, Panel Manufacturing, Erection, Test and Commissioning of 2x52 MVA 13,8/154 kV Transformers and 2 pcs of 220 kV Line Feeders. Mechanical Design of LP Compressed Air System, Cooling Water System, Drainage&Dewatering Systems.

ARTVİN HEPP (2x166 MW)

Mechanical erection,test and commissioning support of generators (2x166 MW), two vertical francis turbines, two inlet valves and related BOP & auxiliaries. Scope includes also Plumbing and Shaft Elevator Design and Erection, Mechanical Atoly Equipment Supply Electrical basic and detailed design, equipment supply, panel manufacturing, erection, test and commissioning of electrical LV and MV BOP & Protection & 380kV switchyard (Including switchyard civil work) on turnkey basis. Other Works in the Scope of This Project Mechanical Design of Plumbing System and Dam Shaft Elevator.

MOGLICE HEPP (2x104,5 MVA+ 1x 1,4MVA)

Erection of Electrical LV BOP & Protection & 220kV High Voltage Power Cables on Turnkey Basis. Mechanical Erection,Test and Commissioning Support of Generators (2x104,5 MVA + 1x1,4MVA), Two Vertical Francis Turbines, One Horizantal Francis Turbines & Three Inlet Valves and Related BOP & Auxiliaries, two 105 MVA Step-up Transformers, one 1,6 MVA  Step-up Transformer, 220kV Gas Insulated Switchgear and MV BOP.

KAVŞAKBENDİ HEPP (3x66,2 MVA)

Mechanical erection,test and commissioning support of generators (3x66,26  MVA), three vertical francis turbines & two inlet valves and related BOP & auxiliaries. Scope includes also design, equipment supply, erection and commissioning of complete Mechanical BOP. Electrical basic and detailed design, equipment supply, panel manufacturing, erection, test and commissioning of electrical LV and MV BOP & Protection & 154kV switchyard (Including switchyard civil work) on turnkey basis. Other Works in the Scope of This Project Basic and detailed design, equipment supply, panel manufacturing, erection, test and commissioning of 3 x 80 MVA  13,8/154 kV transformers and 7 Nos 154 kV Feeder. Basic and detailed design, equipment supply, erection, test and commissioning of  3500 m 1x630 mm2, 154/89 kV high voltage cable. Mechanical Design of LP Compressed Air System, Cooling Water System, Drainage&Dewatering Systems.

ARKUN HEPP (2x6,65 MVA) TOE PLANT

Supply of Turbine, Generator And Auxiliary Equipments Mechanical erection, test and commissioning support of generators (2x6,65  MVA), two horizontal francis turbines, two inlet valves and related BOP & auxiliaries Scope includes also design, equipment supply, erection and commissioning of complete Mechanical BOP Electrical basic and detailed design, equipment supply, panel manufacturing, erection, test and commissioning of electrical LV and MV BOP & Protection on turnkey basis. Other Works in the Scope of This Project Basic and detailed design, equipment supply, panel manufacturing, erection, test and commissioning of 3 x 100 MVA  13,8/380 kV transformers and 2 Nos 380 kV Feeder. Basic and detailed design, equipment supply, erection, test and commissioning of  1500 m 1x630 mm2, 380/220 kV high voltage cable. Mechanical Design of LP Compressed Air System, Cooling Water System, Drainage&Dewatering Systems.

ASLANCIK HEPP (2x66,7 MVA)

Electrical basic and detailed design, equipment supply, panel manufacturing, erection, test and commissioning of electrical LV and MV BOP & Protection & 154kV switchyard on turnkey basis. Other Works in the Scope of This Project Basic and detailed design, equipment supply, panel manufacturing, erection, test and commissioning of 2x66,7 MVA 13,8/154 kV transformers and 3 Nos 154 kV Feeder.

KÖPRÜ HEPP (2x80,5 MVA)

Mechanical erection, test and commissioning support of generators (2x80,56 MVA), two vertical francis turbines & two inlet valves and related BOP & auxiliaries. Scope includes also design, equipment supply, erection and commissioning of complete Mechanical BOP. Electrical basic and detailed design, equipment supply, panel manufacturing, erection, test and commissioning of electrical LV and MV BOP & Protection & 154kV switchyard (Including switchyard civil work) on turnkey basis. Other Works in the Scope of This Project Basic and detailed design, equipment supply, panel manufacturing,  erection, test and commissioning of 2 x 100 MVA 13,8/154 kV transformers and 6 Nos 154 kV Feeder. Mechanical Design of LP Compressed Air System, Cooling Water System, Drainage&Dewatering Systems.

BALIKESİR WPP (52x2,75 MW)

Construction of Switchyard Building, Control Room Building, Social Building, Workshop, Warehouse Building and Guard House. Construction of Foundations for 52 pieces of Wind Turbines and 52 pieces of  Platforms for Wind Turbines Erection. Electrical basic and detailed design, equipment supply, panel manufacturing, erection, test and commissioning of electrical LV and MV BOP & Protection & 154kV switchyard (Including switchyard civil work) on turnkey basis. Other Works in the Scope of This Project Basic and detailed design, equipment supply, panel manufacturing, erection, test and commissioning of 2x110MVA 33/154kV Transformers and 3 Nos of 154kV Feeders.

MENGE HEPP (2x47,2 MVA)

Mechanical erection,test and commissioning support of generators (2x47,22  MVA), two vertical francis turbines & two inlet valves and related BOP & auxiliaries. Scope includes also design, equipment supply, erection and commissioning of complete Mechanical BOP Electrical basic and detailed design, equipment supply, panel manufacturing, erection, test and commissioning of electrical LV and MV BOP & Protection & 154kV switchyard (Including switchyard civil work) on turnkey basis. Other Works in the Scope of This Project Basic and detailed design, equipment supply, panel manufacturing, erection, test and commissioning of 2x63,5 MVA 13,8/154 kV transformers and 5 Nos 154 kV Feeder. Mechanical Design of LP Compressed Air System, Cooling Water System, Drainage&Dewatering Systems.

DERİNER HEPP (4x186 MVA)

Mechanical erection, test and commissioning support of 4 Nos 186 MVA generators Electrical erection, test and commissioning support of 13 Nos 62 MVA single face, step-up transformers 10 Nos Aux. Transformers, 14.4 kV 8650 A Insulated Phase Busduct, 380 kV SF6 GIS Substation and auxiliaries for power house & DAM area. Other Works in the Scope of This Project Mechanical Manufacturing of oil purification unit, oil tanks&lorry.

AKKÖY II HEPP (2x116 MW)

Mechanical erection,test and commissioning support of generators (2x175 MVA), two turbines, two inlet valves and related BOP & auxiliaries.

YEDİGÖZE HEPP (2x158,5 MW)

Mechanical erection,test and commissioning support of generators (2x175 MVA), two Turbines, two Inlet Valves and Related BOP & Auxiliaries. Scope includes also design, equipment supply, erection and commissioning of complete Mechanical BOP. Other Works in the Scope of This Project Mechanical Design of LP Compressed Air System, Cooling Water System, Drainage&Dewatering Systems.

BANDIRMA I CCPP (900 MW)

Electrical erection of MV/LV switchgeras, HV and MV transformers, Bus-ducts,  Generator Circuit Breakers, MV, LV, Control and Instrumentation cables, Cable ways, Instruments, Junction Boxes, Grounding, Lighting and  auxiliary electrical systems, Testing and Commissioning help.

KALKANDERE HEPP (3x18 MW)

Mechanical Equipment supply, erection, test and commissioning support of two (2x175 MVA) generators,two turbines,two inlet valves and related BOP & auxiliaries.

BERKMAN HEPP (3x14,8 MW)

Mechanical erection, test and commissioning support of generators (3x14,8  MVA), three horizantal axis PIT (kaplan) turbines and related BOP & auxiliaries. Electrical basic and detailed design, equipment supply, panel manufacturing, erection, test and commissioning of electrical LV and MV BOP & Control & Automation & Protection & 154kV switchyard (Including switchyard civil work) on turnkey basis. Other Works in the Scope of This Project Basic and detailed design, equipment supply, panel manufacturing, civil work, erection, test and commissioning of  3x14,8 MW 6.3/154 kV transformers & 5 Nos 154 kV feeder. Mechanical Supply of manpower and tools for main revision and controls.

OŞKAN HEPP (3x8,5 MW)

Mechanical erection, test and commissioning support of generators (3x8,5 MVA), three horizantal axis PIT (kaplan) turbines and related BOP & auxiliaries. Scope includes also design, equipment supply installation and commissioning of complete Control, Metering, Protection and electrical systems. 154kV switchyard Control & Automation of Oşkan HEPP Other Works in the Scope of This Project Basic and detailed design, equipment supply, panel manufacturing, civil work, erection, test and commissioning of  3x8,5 MW  6.3/154 kV transformers & 7 Nos 154 kV feeder.  Mechanical Supply of manpower and tools for main revision and controls.

UZUNDERE HEPP (2x26 MW)

Mechanical erection, test and commissioning of two generators, two inlet valves, two vertical pelton turbines and auxiliaries. Other Works in the Scope of This Project Mechanical Supply of manpower and tools for main revision and controls.

CEVİZLİK HEPP (2x50 MW)

Mechanical erection, test and commissioning support of two (2x50 MVA) generators, two turbines, two inlet valves and related BOP & auxiliaries. Other Works in the Scope of This Project Mechanical Manufacturing of two draft tube elbow and two discharge cones. Mechanical Supply of manpower and tools for main revision and controls.

AKKÖPRÜ HEPP (2x65 MVA)

Mechanical erection, test and commissioning support of two (65 MVA) generators,two turbines,two inlet valves and related BOP & auxiliaries.

ULUABAT HEPP (2x54,5 MVA)

Mechanical Erection, test and commissioning support of two (54,5 MVA) generators,two turbines,two inlet valves and related BOP & auxiliaries.

SEYRANTEPE HEPP (2X30 MW)

Mechanical erection, test and commissioning support of generators (2x30  MVA), two vertical francis turbines & two inlet valves and related BOP & auxiliaries. Electrical basic and detailed design, equipment supply, panel manufacturing, erection, test and commissioning of electrical LV and MV BOP & Control & Automation & Protection & 154kV switchyard (Including switchyard civil work) on turnkey basis. Other Works in the Scope of This Project Basic and detailed design, equipment supply, panel manufacturing, civil work, erection, test and commissioning of 2X30 MW 11/154 kV transformers and 5 Nos 154 kV Feeder. Electrical basic and detailed design, Control Panels Manufacturing, erection, test and commissioning of electrical LV and MV BOP & 154kV switchyard Control & Automation of Seyrantepe HEPP.

ERDEMİR BTG (40MW)

Mechanical Erection, piping, insulation works, test and commissioning support Electrical Equipment supply, erection, test and commissioning support

BORÇKA HEPP (2x150 MW)

Mechanical Erection, test and commissioning support of generators ( 2x167 MVA). Electrical Erection, test and commissioning support of Electrical BOP & Switchyard designed by VA TECH HYDRO including design Equipment supply, erection, test and commissoning of HVAC, Lighting, Fire Alarm, Telephone, Clock System and Announcement. Other Works in the Scope of This Project Erection, test and commissioning of 380/154/33/24 kV switchyard complete with 3 Nos 380/154 kV 100 MVA transformers, 1 No 380 kV 183 MVAR reactor, 2 Nos 34.4/380 kV, 3x65 MVA step up transformers 380 kV energy transmission line. Mechanical Manufacturing of oil purification unit, oil tanks&lorry.

ŞANLIURFA HEPP (2 x 23 MW)

Mechanical & Electrical Manpower Support for the erection of the Electromechanical equipment

KAYSERİ CCPP (155 MW)

Mechanical erection of 3 GE LM 6000 Gas Turbine and 1 SIEMENS Steam Turbine Mechanical BOP and Piping. Electrical basic and detailed design, equipment supply, panel manufacturing, erection,test and commissioning of totally 9 Nos 154 kV bay and 1,2 km 2x(3x795MCM) 154 kV OHL. Mechanical Erection, test and commissioning support and partial equipment supply of 3 Aalborg TM 8 Steam Generators.

BURSA CCPP

Mechanical Erection and Insulation of HRSG and Auxiliaries and Site fabrication of Pipe.

LÜLEBURGAZ DESA BOILER

Mechanical Dismantling and Erection of Saturated Steam 18ton/hr 11 bar DESA Boiler

ERDEMİR COGENERATION

Electrical Erection, test and commissioning support of Cogeneration of HRSG, modernization of electrical works.

OSTİM CCPP (35+10 MW)

Mechanical Erection of GES LM 3500 Gas turbine Aalborg boiler,SIEMENS steam turbine and all Mechanical BOP Electrical Erection,test and commissioning support of electrical power distribution, instrumentation and automation systems.

LAMAS GÖKLER HEPP (2x800 kW)

Mechanical Manufacturing of Hydromechanical equipment and erection of sliding gate, grid, penstock, piping and plant overhead crane and environmental lighting installation.

EŞEN II HEPP (2x20 MW)

Mechanical Erection, test and commissioning support of turbines (including embedded parts), butterfly inlet valves and generators. Electrical Erection,test and commissioning support hydraulic control metering and protection equipment for power plant, including switchyard consisting of 5 No's 154 kV bays. Other Works in the Scope of This Project Mechanical Periodic maintenance, inspection & control of two vertical Pelton turbines & generators.

KIRIKKALE MOBILE POWER PLANT (130 MW)

Mechanical Erection of equipment, piping, instrumentation, test and commissioning support of 13x11 MW Diesel Generators, 1 x 10 MW Steam Turbine and Generator, Plant control System, 4 Heat Recovery Steam Generators. Electrical Erection,test and commissioning support

BERKE HEPP (3x174 MW)

Mechanical Erection, test and commissioning support of turbines (including embedded parts), butterfly inlet valves and generators, designed and manufactured by ALSTOM Power Hydro and ALSTOM Power Hydraulique, as member of consortium with ALSTOM Power. Other Works in the Scope of This Project Mechanical Manufacturing of turbine draft tubes,spiralcases,distributors and some generator components designed by ALSTOM POWER Hydraulique (GEC-ALSTHOM / Belford - FRANCE). Mechanical Manufacturing of some turbine components designed by ALSTOM POWER Hydro (NEYRPIC/GRENOBLE - FRANCE). Basic and detailed design, equipment supply, panel manufacturing, civil work, erection,test and commissioning of 154/31,5 kV, 1x25 MVA substation on turn-key basis. Electrical Erection, test and commissioning support of control, metering and protective equipment for power plant including all equipment for intermediate switchyard. Electrical Automation of Power House Draining System including design, material supply and installation works and manufacturing of electrical panels. High Voltage Primary & Secondary, Control / Protection / Metering Design of a New 154 kV Substation.

BİRECİK HEPP (6x 112 MW)

Mechanical Erection of 6 turbines, generators and auxiliaries manufactured by ALSTOM, VA-TECH SULZER ESCHER WYSS and ALSTOM ASEC ENERGY. Other Works in the Scope of This Project Basic and detailed design, equipment supply, panel manufacturing, civil work, erection,test and commissioning of 1 No 380 kV line feeder  on turn-key basis.

BERKE HEPP (3x174 MW)

Mechanical Erection, test and commissioning support of turbines (including embedded parts), butterfly inlet valves and generators, designed and manufactured by ALSTOM Power Hydro and ALSTOM Power Hydraulique, as member of consortium with ALSTOM Power. Other Works in the Scope of This Project Mechanical Manufacturing of turbine draft tubes,spiralcases,distributors and some generator components designed by ALSTOM POWER Hydraulique (GEC-ALSTHOM / Belford - FRANCE). Mechanical Manufacturing of some turbine components designed by ALSTOM POWER Hydro (NEYRPIC/GRENOBLE - FRANCE). Basic and detailed design, equipment supply, panel manufacturing, civil work, erection,test and commissioning of 154/31,5 kV, 1x25 MVA substation on turn-key basis. Electrical Erection, test and commissioning support of control, metering and protective equipment for power plant including all equipment for intermediate switchyard. Electrical Automation of Power House Draining System including design, material supply and installation works and manufacturing of electrical panels. High Voltage Primary & Secondary, Control / Protection / Metering Design of a New 154 kV Substation.

BERKE HEPP (3x174 MW)

Mechanical Manufacturing of some turbine components designed by ALSTOM POWER Hydro (NEYRPIC/GRENOBLE - FRANCE). Other Works in the Scope of This Project Basic and detailed design, equipment supply, panel manufacturing, civil work, erection,test and commissioning of 154/31,5 kV, 1x25 MVA substation on turn-key basis. Mechanical Manufacturing of turbine draft tubes,spiralcases,distributors and some generator components designed by ALSTOM POWER Hydraulique (GEC-ALSTHOM / Belford - FRANCE). Mechanical Erection, test and commissioning support of turbines (including embedded parts), butterfly inlet valves and generators, designed and manufactured by ALSTOM Power Hydro and ALSTOM Power Hydraulique, as member of consortium with ALSTOM Power. Electrical Erection, test and commissioning support of control, metering and protective equipment for power plant including all equipment for intermediate switchyard. Electrical Automation of Power House Draining System including design, material supply and installation works and manufacturing of electrical panels. High Voltage Primary & Secondary, Control / Protection / Metering Design of a New 154 kV Substation.

KEMERKÖY TPP (3x210 MW)

Electrical Erection, test and commissioning support of electrical power distribution, instrumentation and automation systems

PAMUKOVA HEPP (3x3,5 MW)

Mechanical Erection of electromechanical equipment consisting turbine, gear box, generator, hydraulic governor, cooling water system.

BERKE HEPP (3x174 MW)

Mechanical Manufacturing of turbine draft tubes,spiralcases,distributors and some generator components designed by ALSTOM POWER Hydraulique (GEC-ALSTHOM / Belford - FRANCE). Other Works in the Scope of This Project Mechanical Manufacturing of some turbine components designed by ALSTOM POWER Hydro (NEYRPIC/GRENOBLE - FRANCE). Basic and detailed design, equipment supply, panel manufacturing, civil work, erection,test and commissioning of 154/31,5 kV, 1x25 MVA substation on turn-key basis. Mechanical Erection, test and commissioning support of turbines (including embedded parts), butterfly inlet valves and generators, designed and manufactured by ALSTOM Power Hydro and ALSTOM Power Hydraulique, as member of consortium with ALSTOM Power. Electrical Erection, test and commissioning support of control, metering and protective equipment for power plant including all equipment for intermediate switchyard. Electrical Automation of Power House Draining System including design, material supply and installation works and manufacturing of electrical panels. High Voltage Primary & Secondary, Control / Protection / Metering Design of a New 154 kV Substation.

ÇAYIRHAN THERMAL POWER PLANT (2X150 MW)

Electrical Equipment supply, construction and erection of auxiliary electrical energy systems of plant site facilities for Units 3 and 4

ÇAMLICA HEPP (3x28 MW)

Electrical Erection of 154 kV switchyard and auxiliary electrical systems

BERKE HEPP (3x174 MW)

Electrical Erection, test and commissioning support of control, metering and protective equipment for power plant including all equipment for intermediate switchyard. Other Works in the Scope of This Project Mechanical Erection, test and commissioning support of turbines (including embedded parts), butterfly inlet valves and generators, designed and manufactured by ALSTOM Power Hydro and ALSTOM Power Hydraulique, as member of consortium with ALSTOM Power. Mechanical Manufacturing of turbine draft tubes,spiralcases,distributors and some generator components designed by ALSTOM POWER Hydraulique (GEC-ALSTHOM / Belford - FRANCE). Mechanical Manufacturing of some turbine components designed by ALSTOM POWER Hydro (NEYRPIC/GRENOBLE - FRANCE). Basic and detailed design, equipment supply, panel manufacturing, civil work, erection,test and commissioning of 154/31,5 kV, 1x25 MVA substation on turn-key basis. Electrical Automation of Power House Draining System including design, material supply and installation works and manufacturing of electrical panels. High Voltage Primary & Secondary, Control / Protection / Metering Design of a New 154 kV Substation.

SEYHAN II HEPP (3x2,9 MVA)

Mechanical erection including piping works, testing and commissioning of horizantal axis kaplan bulb type HEPP.

KARGILIK HEPP (2x15 MVA)

Basic and detailed design, equipment supply, panel manufacturing, erection, test and commissioning of 11/154 2 x 15 MVA Switchyard. High Voltage Primary Secondary, Control / Protection / Metering Design of a New 154 kV SUBSTATION for Kargılık HEPP.
